Oilless Bearing

Definition

Self-lubricating copper bushings, also known as graphite copper bushings, self-lubricating wear-resistant bushings, self-lubricating bearings, self-lubricating shaft sleeves or self-lubricating guide sleeves, are mechanical bushings that can maintain good sliding performance without the need for additional lubricating oil. Its main material is high-strength brass, and solid lubricants (such as graphite) are evenly inlaid on the surface of the copper sleeve. This structural design enables the copper sleeve to automatically release lubricating substances during operation, forming a stable lubricating film, which significantly reduces the coefficient of friction and wear rate. The Zhaoxu Automation self-lubricating copper sleeve is made of high-strength brass as the main material, which itself has excellent compressive strength and corrosion resistance.

Core value

Dual-effect self-lubricating system: Embedded high-purity graphite + surface micro-porous oil storage structure

Integrated flanging design: Axial positioning accuracy ±0.03mm, anti-overturning moment increased by 50%

Military-grade wear resistance: Special copper alloy formula (CuSn8/CuPb24), with a service life five times that of ordinary copper sleeves

Ready-to-use: Pre-lubricated, no running-in period required



Technical parameters

Parameter standard type, heavy-duty type, high-temperature type

The base materials are CuSn8 tin bronze, CuPb24 lead bronze and aluminum bronze

Graphite purity ≥99.9% ≥99.9% ≥99.95%

The flanging thickness is 3.0mm, 4.5mm and 3.5mm

Radial load-bearing capacity: 120MPa, 180MPa, 150MPa

Axial load capacity: 80MPa, 120MPa, 100MPa

Operating temperature: -30℃ to +180℃, -20℃ to +200℃, -50℃ to +250℃



Four major technological breakthroughs

Gradient copper layer structure: A gradual transition from a high-hardness surface layer to a tough substrate

Intelligent lubrication system: Laser micro-hole oil storage technology, with a 40% increase in lubricant retention

Flanging reinforcement: Radial reinforcing rib design enhances the anti-deformation capacity by 60%

Environmental protection upgrade: Lead-free formula is available



Typical application scenarios
Construction machinery: Excavator bucket connection seat (Dust-proof type)
Shipbuilding Industry: Steering gear thrust Bearings (Seawater-resistant version)
Industrial equipment: Heavy-duty machine tool guide rails (high-precision type)
Food machinery: Filling equipment Rotary Table (FDA-certified model)



Deep customization service

Non-standard sizes (Φ3-200mm)

Special surface treatment

Laser marking of enterprise logos



Why choose us?

●We are constantly expanding our product line to meet the evolving needs of our customers.

●We believe that all aspects of business operations need to be constantly pushed forward in order to achieve long-lasting success.

●Our state-of-the-art facility is equipped with the latest technology to ensure accuracy and consistency.

●With strong technical strength, rich production experience, perfect service system, brand-new marketing concepts, to go to a broader market, providing advanced products and services for my country's industrial automation system is our unremitting pursuit!

●We believe in transparency and open communication with our customers.

●Let us work together to actively develop environmental protection requirements, energy-saving, high-quality and efficient new Bronze Shoulder Bushings to serve the industry.

●We are a trusted partner for businesses across a range of industries.

●Our company strives to create a platform for every employee to develop, improve and realize their value, and provide a broad space for development to every employee who aspires to be a success, so that employees can bring out their maximum potential.

●We understand the importance of timely delivery and strive to meet all deadlines.

●We take it as our purpose to provide customers with advanced, high-quality, reasonable and economical Bronze Shoulder Bushings, and to build a world-class brand as our goal.
